Speed-X 8700 2D Wireless Barcode Scanner 2.4GHz with Stand, Receiver & Charging Cable

Speed-X 8700 2D Wireless Barcode Scanner with Stand

The Speed-X 8700 2D Wireless Barcode Scanner is a reliable and versatile barcode scanning solution designed for retail stores, offices, warehouses, inventory management, logistics, and other business environments. With 2.4GHz wireless connectivity, the scanner provides convenient cable-free operation while maintaining a stable connection with compatible devices.

Supporting both 1D and 2D barcode scanning, the Speed-X 8700 can read commonly used barcodes such as Code 128, EAN-13, EAN-8, UPC-A, UPC-E, Code 39, Code 93, Codabar, ITF-25, QR Code, Data Matrix, and PDF417.

The scanner features a 640 × 480 CMOS image sensor with a minimum resolution of approximately 5 mil, allowing it to capture a wide range of retail and business barcodes. Its wide field of view and flexible scanning angles make it suitable for everyday counter, checkout, inventory, and product scanning applications.

Reliable 2.4GHz Wireless Connectivity

The Speed-X 8700 uses 2.4GHz wireless technology operating between 2.402GHz and 2.480GHz. It provides a transmission range of up to 30 meters in an open area, giving users greater freedom to move around while scanning products, inventory, packages, or documents.

The scanner supports multiple operating modes, including Real-Time Mode, Cache Mode, and Inventory Mode, making it useful for both real-time scanning and situations where barcode data needs to be temporarily stored.

Rechargeable Battery for Convenient Operation

A built-in 2000mAh rechargeable lithium battery provides power for wireless scanning without requiring the scanner to remain connected by cable. The battery can be fully charged in approximately 6 hours.

The included stand and charging cable provide additional convenience for counter-based scanning and regular daily use.

1D & 2D Barcode Scanning

The Speed-X 8700 supports a variety of popular barcode formats.

1D Barcode Support:

• Code 128
• EAN-13
• EAN-8
• UPC-A
• UPC-E
• ITF-25
• Interleaved 2 of 5
• Code 39
• Code 93
• Codabar

2D Barcode Support:

• QR Code
• Data Matrix
• PDF417

Designed for Business & Everyday Scanning

With its ergonomic handheld design, wireless functionality, rechargeable battery, and included stand, the Speed-X 8700 is suitable for a variety of applications, including:

• Retail stores and checkout counters
• Supermarkets and shops
• Warehouses and inventory management
• Logistics and shipping
• Offices
• Product tracking
• Stock management
• Point-of-sale environments
• Package and parcel scanning
• Business data entry

The scanner also features beeper and LED indicators to provide clear feedback during scanning.

3. Key Features

• 2D Wireless Barcode Scanner with 2.4GHz connectivity
• Supports 1D and 2D barcode scanning
• Reads QR Code, Data Matrix and PDF417
• Supports popular retail barcodes including EAN, UPC, Code 128 and Code 39
• 2.4GHz wireless transmission for convenient cable-free scanning
• Wireless range of up to 30 meters in an open area
• 2000mAh rechargeable lithium battery
• Supports Real-Time, Cache and Inventory Modes
• 640 × 480 CMOS image sensor
• Minimum scanning resolution of approximately 5 mil
• Includes scanner stand, wireless receiver and charging cable
• USB HID Keyboard / USB VCP interface support
• Beeper and LED scanning indicators
• Suitable for retail, warehouse, inventory, logistics and office use

4. Technical Specifications

• Model: Speed-X 8700
• Product Type: 2D Wireless Barcode Scanner
• Scanning Type: 1D & 2D Barcode Scanner
• Wireless Technology: 2.4GHz
• Wireless Frequency: 2.402–2.480GHz
• Transmission Range: Up to 30m in an open area
• Communication Modes: Real-Time Mode / Cache Mode / Inventory Mode
• Battery: 2000mAh Lithium Battery
• Charging Time: Approximately 6 hours
• Interface: USB HID Keyboard / USB VCP
• Input Voltage: DC 5V ±5%
• Maximum Current: 120mA
• Image Sensor: 640 × 480 CMOS
• Field of View: 36° Horizontal / 27° Vertical
• Minimum Resolution: Approximately 5 mil
• Scanning Angle: Corner 180°
• Elevation Angle: ±55°
• Deflection Angle: ±55°
• Indicator: Beeper and LED
• Scanner Dimensions: 90 × 67 × 168mm
• Scanner Weight: Approximately 130g
• Operating Temperature: -20°C to +60°C
• Storage Temperature: -40°C to +80°C
• Operating Humidity: 5%–95%, non-condensing
• Included Accessories: Stand, Wireless Receiver and Charging Cable

5. Package Includes

• 1 × Speed-X 8700 Wireless Barcode Scanner
• 1 × Wireless Receiver
• 1 × Scanner Stand
• 1 × Charging Cable
